Extron MAAP 304 IS Montagekit - Zwart

Productbeschrijving

Extron MAAP 304 IS Montagekit - Zwart kenmerken

MAAP Mounting Frame for Three Module Boxes

Extron MAAP 304 IS, 114 mm, 2,5 mm, 70 mm

The Extron MAAP 304 IS is a mounting frame with room for up to four single-space MAAP - Mini Architectural Mounting Plates. The MAAP 304 IS is compatible with BTicino 503E, Gewiss GW 24 203, and Vimar V71613 or V71303 three module electrical mounting boxes with 83.5 mm center screw distance. Available in a black finish. Dimensions: 2.75" x 4.5" x 0.1" (7 x 11.4 x 0.25 cm).

- Accepts up to four single-space MAAP - Mini Architectural Adapter Plates — Extron MAAPs are designed for easy installation in a wall, lectern, boardroom table, or other AV presentation furniture to maintain a clean and efficient AV system design. MAAPs sold separately.
- Designed for wall, lectern, boardroom table, or other AV presentation furniture
- Compatible with BTicino 503E, Gewiss GW 24 203, and Vimar V71613 or V71303 junction boxes
- Fits many three module electrical mounting boxes with 83.5 mm center screw distance
- Custom engraving available — Allows labeling of individual connector modules. Available at additional charge.
- Available in black
- Dimensions: 2.75" x 4.5" x 0.1" (7x 11.4 x 0.25 cm)
